Installation
26
Connect the guide to the pin.
Secure the guide to the support with a bolt, washer and nut.
Ready the guide.
Position the guide on the support.
1x M8 x 16
1x 8.4-21-4
1x M8
Screw in the ball handle for adjusting the height of the support
wheel.
