TIELBURGER tk 520 - Page 27

Installation
27
Tighten the bolt.
Correctly secured guide.
Ready the liing linkage.
Note: e liing linkage is part of the mounting frame.
2x SW 13
Push the bolt through the hole in the tab.
Turn the washer and nut on the bolt.
1x M12 x 30
1x 13-24-2
1x M12
