Tiger Bengal - Step 15: Storm Braces; Attaching Storm Braces

Pleaseretaininstruconsforfuturereference
15
Step 16:
FIT INTERNAL SKIRTING
• Arrangetheskirngaroundtheoutsideedgeofoor(internally),measureandcutdownifrequiredtobest
 matchtheinternalspace.
• Secureeachskirngseconintoplaceusing3xS40evenlyspacedalongthelength.
(Detail O1 & O2)
NOTE: DO NOT FIX THE SKIRTING TO THE FLOORBOARDS.
O1 O2
S40
SKIRTING
Step 15:
ATTACH STORM BRACES
• Fixstormbracestotheinsideofgableswith2xCB40provided.AlwaysleavetheboomCB40slackenough
 toletthestormbracemoveasthecabinexpandsandcontracts.
(Detail N1 & N2)
N2
N1
STORM
BRACE
