Tiger Delta User Manual

Pleaseretaininstruconsforfuturereference
07
Step 2:
DOUBLE DOOR ASSEMBLY
• Forcabinswithdoubledoors,buildupdoorframeusingthefourdoorcomponentsprovided.
 Removesuppliedkey.Thisisusuallystapledoverkeyhole.
• Arrangethedoorframingontoarmandlevelsurface,withhingestotheground.Slotthedoorsill(base)
 thenthedoorheadintoplace.Securethe4seconstogetherthroughthejointsusing1xS60percorner.
(Detail B)
NOTE: HOLES FOR FRAMING ARE PRE-DRILLED IN THE FACTORY.
NOTE: THIS IMAGE IS FOR ILLUSTRATIVE PURPOSES AND DOOR STYLE MAY DIFFER FROM YOUR
SUPPLIED PRODUCT.
NOTE: 14 CABINS COME SUPPLIED WITH SINGLE PIECE HEADER FASCIAS FOR DOORS AND
WINDOWS. SEE STEP 15 FOR INSTALLATION.
B
DOOR HEAD
DOOR SILL (BASE)
S60
