Cheetah Common Section 6-23
ITEM PART NO. QTY. DESCRIPTION
1 6T1031 1 SPROCKET
2 6T1016 1 BEARING LOCK NUT - THICK
3 22596 1 JAM WASHER
4 6T1015 1 BEARING ADJUSTMENT NUT - THIN
5 6T1014 1 BEARING ADJUSTMENT SLEEVE
6 6T1011 1 UPPER SEAL - SET OF 2
7 6T1012 1 BEARING CONE
8 6T1013 1 BEARING CUP
9 33423 1 SPINDLE HOUSING
10 30570 1 STREET ELBOW
11 6T3208 1 GREASE ZERK
12 6T1013H 1 BEARING CUP
13 6T1012H 1 BEARING CONE
14 6T1011H 1 LOWER SEAL
15 6T1019 1 SPINDLE KEY
16 PT1018H5 1 SPINDLE
17 06503064 1 O-RING PLUG,1/8”
ROTARY SPINDLE ASSEMBLY
