Tiger PDU-A30U User Manual

99
2
Part Names and Accessories
Spout
Dispense lever
Mesh filter
Prevents entry of foreign objects into
the pump.
Steam vent
Steam is emitted
when boiling.
Receptacle
Handle
Bottom
Turns 360°.
Water volume indicator
Open /close lever
M
A
X
Lid
Location
for discarding
hot water
Inside container
Lid gasket
Hinge
Maximum water
level
Keep water above
this level.
Water level line
Rell water
mark
Be sure the power cord is attached
when you turn the swivel bottom.
Caution
The numbers such as 208, 194, 176, 158
indicated in this instruction manual are
only approximate temperatures.
Display area
Keep warm lamp
Boil lamp
〈 Operation Panel 〉
Energy Saving key
Unlock keyTemp.Set key
Re-Boil/Timer key
Unlock lamp
Appliance plug Plug
〈 Power Cord 〉
Plug
( Plug into an outlet. )
Appliance plug
( Plug into the insert
slot of the unit. )
When the water is being boiled, bubbling
sounds can be heard from inside the
container. This is normal and does not
indicate a malfunction.
Sounds

Tiger PDU-A30U Specifications

General

Brand	Tiger
Model	PDU-A30U
Category	Water Heater
Language	English
