Timber Tuff Tools TMG-243PT - Manual Tube

Page
11
of 26
2. MANUAL TUBE
Using the hardware listed below and a No. 3 Phillips head screwdriver, assemble the manual tube
(#46) to the back frame as shown. Remove the cap from the manual tube (#46) to gain access to the
center mounting hole.
2x
M6 X 20 mm
Phillips Pan
Head Screw
#50
2x
M6 Flat
Washer
#48
2x
M6 Split Lock
Washer
#49
1x
Manual Tube
#46
