Time Versalift SST-40-EIH - Sst-37-Eih Dimensional Specifications

3-5
28009-09 09/16VERSALIFT SST-37/40-EIH
SPECIFICATIONS
SST-37-EIH DIMENSIONAL SPECIFICATIONS
Horizontal Reach .................................................................................................................27 ft 9 in. (8.5 m)
Standard Platform Capacity................................................................................................. 300 lbs. (136 kg)
Maximum Platform Capacity................................................................................................ 450 lbs. (204 kg)
Outer Boom Lift Eye Capacity ............................................................................................. 500 lbs. (227 kg)
Height to Bottom of Platform ............................................................................................. 37 ft. 0 in (11.3 m)
Working Height ..................................................................................................................42 ft. 0 in (12.8 m)
Stowed Travel Height ........................................................................................................10 ft. 4 in (3.15 m)
Weight of Lift without oil and mounting hardware ............................................................ 2230 lbs. (1012 kg)
Hydraulic System
Operating Pressure .................................................................................................... 2250 PSI (158 kg/cm
2
)
Flow Rate ..............................................................................................................................3 GPM (11 lpm)
Filtration ................................................................................................................................10 micron return
100 mesh suction
System Type ............................................................................................................................... Open center
Boom Action
Inner-Boom .............................................................................................................. 116 in (2.9 m) Extension
Outer-Boom .................................................................................................................................-14° to +74°
Outer-Boom (With Ground-Access Option) .................................................................................-20° to +75°
Lower-Boom .............................................................................................................................. -7
o
to vertical
Insulation Gap
Upper Boom fully retracted ......................................................................................................42 in. (1.07 m)
Lower Boom Insert (optional) ....................................................................................................12 in. (0.3 m)
Upper Boom fully retracted w/o Electroguard ..........................................................................10 in. (0.25 m)
Ambient Temperature Range for Structural Integrity ...................................... -40°F (-40°C) to 125°F (52°C)
Notes:
1. All dimensions and angles are nominal, based on 40 in. (1.02m) frame height.
2. The total load in the platform including operator, liner, tools, etc. Must not exceed the maximum platform
capacity.
