5
• Fix the back plate to the wall. Take care not to over-tighten the screws
to prevent damage to the back plate. If using a power screwdriver,
use the lowest torque setting
• Terminate the cable into the terminal block ensuring correct polarity
is observed and that all bare conductors are sleeved (see below details
on connection).
7. Connection
Connect the mains supply cable to the terminal block on the back plate
as follows (see connection diagram E):
NEUTRAL (Blue) N
EARTH (Green/Yellow)
LIVE (Brown) L
Connect the cable from the lighting load to the terminal block on the
backplate as follows;
EARTH (Green/Yellow)
NEUTRAL (Blue) N
SWITCH LIVE (Brown) L
1
Ensure all connections are secure.
Line the unit up with the back plate, apply pressure to both sides of the unit
until both catches click into place to ensure a weatherproof seal.
