Output
ON light
Returns TG77 to
operating mode
with clock time
displayed
Decreases hours,
minutes, days/day
groups during
programming and
setting clock time
Increases hours,
minutes, days/day
groups during
programming and
setting clock time
Initiates countdown
time period
Initiates random
delay to both start
time and stop time of
every programme
Increments
programming steps
and when held
pressed for
approximately
4 seconds initiates
clock set mode
Override to next
programme change,
also gives permanent
ON/OFF and also
suspends and
reinstates programmes
Tamper proof reset
button (use pen or
similar implement)
Diagram A
