T300 T550 Hardware Installation Guide. Page 12
6.4. Connecting RS232 Serial Console Cable
The T300 T550 Console port is a RS232 serial port on a standard 9-way D-type connector. The console serial port can
be used configure the device from a host PC.
Using the supplied null modem cable, connect the T300 T550 console port to the RS232 serial port on a PC.
A terminal emulation program, such as Hyper-Terminal or Putty, can then be used to configure the device.
Terminal settings:
Connect Using: Direct to COMx (where x is the serial port number)
Bits per second: 115200
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
Terminal Emulation: VT100 / ANSI
Please refer to the T-Series User Guide (Document Number T1300-01) for configuration information.
6.5. Applying Power
Apply power by inserting the supplied mains cable into the IEC inlet at the rear of the NTP server and into an appropriate
AC power source.
CAUTION:
For PERMANENTLY CONNECTED EQUIPMENT, a readily
accessible disconnect device shall be incorporated external to the
equipment.
For PLUGGABLE EQUIPMENT, the socket-outlet shall be installed
near the equipment and shall be easily accessible.
Verification of the protective earthing connection of the socket-outlet
by a skilled person is required for the safe use of the product.
2020 TimeTools Limited. All Rights Reserved.
