Back Light
1. Go to choose Back Light menu
2. Set back light time-out duration and Brightness level
10 sec; 20 sec; 30 sec; 45 sec; 60 sec; 90 sec; 120 sec; 180 sec; ON
Dim level: High; Medium; Low
Language Setting
1. Go to choose Language menu
2. Choose below languages
English
Frangais
Deutsch
Italiano
Factory reset
Return to factory original settings.
SW version
Check software version of the unit.
Long press Menu/Enter to return during above settings.
PRESET
Store DAB/FM stations
1. Under DAB or FM mode, tune to the DAB or FM stations you want to store, hold PRESET for 2 seconds to into
Preset Save menu, press TUNE+/- to choose list of stored presets from P1 to P10.
2. If you want to store at P1, press SELECT to confirm, then “Preset 1 Saved” will be displayed to show P1 is stored.
3. If you want to store at other presets, repeat above operations.
4. Total 10 DAB stations and 10 FM stations can be stored.
Play stored stations
1. Press PRESET to into Preset Recall menu, press TUNE+/- to pick up stored radio stations from P1 to P10.
2. Press Menu/Enter to confirm to play.
3. ##Empty is displayed if no radio station stored.
OTHER SETTINGS
Volume control
1. Adjust volume by turn around volume wheel
2. Under Bluetooth mode you can adjust volume by audio device themselves.
Battery volume
1. Battery volume is displayed when powered by battery as picture
2. The unit will turn off automatically after battery volume is totally consumed to protect ifself.
External earphone
When connect earphone/headphone to EARPHONE port, speaker output is turned off automatically.
Signal strength adjustment
1. For best signal under DAB or FM mode, position the unit in an open area and fully extend the antenna.
