12. Technical data
Voltage and frequency
• 110 - 240 volts ac, 50 - 60 Hz (Power supply)
• 12 volts dc
Current load MC1100 only
• 8-10 Watt at 110 - 240 volts ac
• max 500mA at 12 volts dc
Operating temperature range
• 0° C to +45° C
Storage temperature
• - 15° C to + 55° C
weights and sizes
• TIPES
MC1100 clock:
200 (l) * 112 (d) * 64(h) mm
3
, 0,28 kg
• TIPES
reading unit:
224.2 (l) * 200 (d) * 72.4 (h) mm
3
, 0.57 kg
• control unit:
200 (l) * 112 (d) * 64 (h) mm
3
, 0.48 kg
• quad-field trap:
568 (l) * 263 (d) * 39 (h) mm
3
, 4.0 kg
Accessories
• mains power supply
• home cable for USTB connection
• cable reading unit-control unit 1,5m
13. Guarantee-conditions:
The manufacturer, Motz Computer GmbH, offers the following guarantee to the first purchaser of
TIPES
components:
1. The guarantee is valid for 12 months, batteries 6 months, commencing when the unit is handed
over to the purchaser which must be verified by purchaser invoice or similar documentation.
2. The guarantee covers all parts or components which fail due to faulty workmanship or faulty
material. The guarantee does not cover TIPES
components where defects or poor performance are
due to misuse, faults in the building wire, accidental damage, neglect, faulty installation,
unauthorized modification or attempted repair or failure to use the unit in accordance with the
operating instructions.
3. Should guarantee repairs be necessary the purchaser must inform the nearest customer service
(distributor or authorized service partner).
4. The guarantee or free replacement includes both labor and materials.
5. Repairs carried out under guarantee do not extend the guarantee period. Parts removed during
guarantee repairs become the property of Motz Computer GmbH.
