Tippmann Bravo One ELITE - Getting Started

8
E
N
G
L
I
S
H
Getting Started
• Eyeprotectiondesignedforpaintballusemustbewornbytheuserandanyperson
withinrange.
• Donotdisassemblethismarkerwhileitispressurized.
• Donotpressurizeapartiallyassembledmarker.
• Readeachstepcompletelybeforeperformingthestep.
NOTE:Carefullyhandstartallthreadedpartswhenassembling,anddonotovertighten,as
thismaypotentiallystripthethreadedparts.RefertotheParts Diagramonpages20and21
fortheseinstructions(itemnumbersareinparentheses).
WARNING
Install the air supply and load the hopper with paintballs only after you:
• have a Barrel Blocking Device installed (see page 4)
• have the Trigger Safety in Safe mode (see page 6).
Eye protection designed for paintball use must be worn by the user
and any person within range.
1. Install the Barrel
a. Makesurethe
BarrelO-Ring(15)
isinplaceonthe
endoftheBarrel.
b. SlidetheBarrelthroughtheShroudandturnitclockwisetothreaditintothe
Receiver.
2. Install the Components to the Marker
Collapsible Stock
a. Finda10-32x1/2”blackscrew(B)inthe
MaintenancePack.
b. InserttheStockintotheslotsontheEndCapof
themarker(A).
c. Insertandtightenthescrew(B).
Length Adjustment
1. SqueezetheAdjustmentLever.
2. SlidetheStocktogetheroraparttothe
desiredlength.
3. ReleasetheAdjustmentLever.
Feed Elbow
a. RefertoFigures12and14onpages16-17beforeattemptingtoinstalltheFeed
Elbow.AligntheFeedElbowpinswiththetwobossesontherightsideofthe
marker.
b. Insertthepinsintothebosses.
c. TipupuntiltheFeedElbowlocksintoplace.
a
B
2
1
3
Figure 2: Install and Adjust Stock
Figure 1: Install the Barrel.
51
15
Shroud aSSemBLy
