Tischer Trail 200 - Raising the Cabin (280; 280 S Only)

16 of 90
3.5 Raising the cabin (280 / 280 S only)
Attention
Risk of damage
•
In case of vehicles with air suspension, the air suspension must be
completely lowered.
Mounting the front crank supports
Remove front crank support 2 from the stowage box and insert it into the adapter on the cabin.
Fold support strut 3 up and secure it to the cabin using wing screw 1.
