73 of 90
8.2 Support struts (awnings only, which do not exceed the length of the
cabin)
Follow instructions 1 on the supporting struts in order to install the supports.
The supporting struts are inserted into respective holders on the vehicle.
Supporting the awning
In order to insert strut 3, slide locking mechanism 1 of holder 2 upward, insert the strut and slide
locking mechanism 1 downward again.
