2 Installation Wizard
The installation wizard will guide you to finish the final assembly of your new mower easily.
2.1 Tool Required
• 1/2” Ratchet Wrench with 13mm,16mm,24mm sleeves
• 17-19, 22-24
• Spanner Side cutter or Industrial Scissors
• Safety Goggles and Gloves
2.2 Torque Application
2.3 Installation
Cut all zip ties and disassemble shipping crate.
Step1: Installing Long, Short Pivot Bar, Upper Lift bracket and Fittings
Remove the packaging of long, short pivot bar, upper lift bracket and fittings Assemble all above parts
on the mower deck body.
Parts: 2pcs of long pivot bars, 2pcs of short pivot bars, 1pcs of upper lifting bracket, 4pcs of bolts M16x50, 9pcs of
plain washers 16, 5pcs of locknut M16, 1pcs of bolt M16x110 and 2pcs of bushings. Tighten locknut completely.
Torque Values Chart for Common Bolt Sizes
Bolt Size Bolt Head Identification
(Metric) Class 8.8
Metric N.M Ft-lb
M16x50, M16x95 225 165
Torque tolerance +0%, -15% of torquing values. Unless otherwise
specified use torque values listed above.
To Next Page
