Section 2: Model Specifications & Performance
General Stats:
• Wingspan: 1607mm
• Wing area: 3205cm
2
• Maximum take-off Weight: 5kg
• Cruise speed: 60-70kph
• Recommended prop diameter: 9-10 inches
Aerodynamic Properties:
• Root airfoil: NACA 3410
• Tip airfoil: NACA 3410
• Root chord: 240mm
• Tip chord: 95mm
• Average Chord: 173mm
• Root incidence: 3°
• Tip incidence: 0°
• Aspect ratio: 7.95
• Max L/D: 14.5
• Dihedral: 0°
• Sweep: 2°
