Section 3: Required Build Materials
Spars needed:
(2) 8x1000mm (main wing spars)
(4) 3x400mm (wingtips + aileron hinge)
(2) 4x230mm (tail support)
(2) 3x230mm (taileron hinge)
(2) 2x70mm (front tail support – optional)
Recommended motor & prop:
16-19mm mounting pattern
2212 / 2216 1000 kv or similar
9-10 inch CW/CCW propeller
Recommended electronics:
TBS crossfire / ELRS / Dragonlink
5.8ghz / 1.2ghz video (19x19 camera)
Matek F405-WTE flight controller or similar
Matek M8Q-5883 GPS/Compass or similar
35a BLHeli ESC
(4) Emax ES08MAII servos
Battery: Anything from a 7,000mah 4S/6S Lipo to 4S6P 21,000mah 18650 Li-Ion
Misc:
Polymaker Polylite prefoamed LWPLA
Polycarbonate or other high-temp filament for the motor mount
Medium CA glue
220x220x250 minimum size print bed (Ender 3)
Control horns (this one).
M3 threaded inserts (max 6mm height)
M3 bolts of various sizes
6x3mm magnets
