7/21
5
SUPPORT ASSEMBLY
Standard heavy duty supports are always shipped assembled. See FIGURE 2 for component breakdown.
IT IS THE CUSTOMERS RESPONSIBILITY TO LAG THE SUPPORTS TO THE FLOOR
AFTER THE FOLLOWING INSTALLATION PROCEDURES HAVE BEEN MET.
1. If supports have been provided bolt them to the frame. Generally there are tapped pads welded to frame sections
for the supports to bolt up to. See FIGURE 2.
FIGURE 1
CAUTION
!
FIGURE 2
TITAN CONVEYORS
CONVEYOR:
SECTION:
JOINT:
TITAN CONVEYORS
CONVEYOR:
SECTION:
JOINT:
J3247 J3247
1 2
1 1
NOTE! LOWER SECTION NUMBERS START
AT THE CONVEYOR INFEED.
HEAVY DUTY
SUPPORTS
TAPPED
PADS
