2
3. An extension cord retainer (20) is built into the rear
handle that prevents the extension cord from pulling out of
the handle. To use this feature, simple double the extension
cord, about a foot from the end, and insert it into the hole of
the handle. Hook the loop formed by doubling the cord over
the cord retainer. Gently tug on the cord to ensure that it is
firmly retained in the handle. Plug the receptacle end of the
extension cord into the tool's power supply cord. (See Fig.
16).
The chain saw will automatically stop when the switch
trigger is released. The lock-off button will have to be
depressed and the switch trigger squeezed to restart the
motor.
2). Grip the product with both hands, left hand holding the
front handle (do not hold chain brake) and the right hand
holding the rear handle. Press the lock-off button, then fully
press the switch trigger and hold in this position. The lock-
off button can now be released now. (See Fig. 15a, 15b).
NOTE: It is not necessary to maintain pressure on the lock-
off button once the switch trigger is squeezed and the motor
is running. The lock-off button is a safety device to avoid
accidental starting
The chain brake is a safety mechanism activated through
the front hand guard. When kickback occurs, chain stops
immediately. The following function check should be carried
out at regular intervals. The purpose of the chain brake
testing is to reduce the possibility of injury due to kickback.
2. STOP CHAIN SAW.
4. CHAIN BRAKE.
Fig. 16
Fig. 15a
Fig. 15b
WARNING! If the chain and motor fail to stop when
the chain brake is engaged, take the saw to the
nearest authorized dealer. Do not use the saw if the chain
brake is not in proper working.
