EN
30
In more detail...
TTB820GGT by TITAN
UK plug (only for UK market)
If you need to replace the tted plug, then follow the instructions below.
IMPORTANT: The wires in the mains lead are coloured in accordance with the
following code:
Blue – Neutral
Brown – Live
As the colours of the wire in the mains lead of this product may not correspond
with the coloured marking identifying the terminals in your plug, proceed as
follows. The wire, which is coloured blue, must be connected to the terminal,
which is marked with N or coloured black. The wire, which is coloured brown,
must be connected to the terminal, which is marked L or coloured red.
13 AMP fuse
approved to
BS 1362
Brown L(Live)
Cable grip
Outer sleeve
Connect
Blue to
N(Neutral)
WARNING! Never connect live or neutral wires to the earth terminal
of the plug, which is marked with E.
Only t an approved 13 Amp BS 1363 or BS 1363/A plug and the correctly rated
fuse.
If in doubt, consult a qualied electrician.
NOTE: If a moulded plug is tted and has to be removed take great
care in disposing of the plug and severed cable, it must be destroyed
to prevent engaging into a socket.
Care and maintenance
