Titan TTB820GGT User Manual

EN
29
In more detail...
TTB820GGT by TITAN
Care and maintenance
Rell the trimming line in the trimming spool
1. Remove the trimming spool (12c) from the housing (12e) as instructed in
chapter “Trimming line - Replace the trimming spool”.
2. Discard all the remaining lines (12d) from the trimming spool (12c).
3. Clean the housing (12e) and the trimming spool (12c).
4. Cut two new 3 m long trimming lines with a diameter of 1.6 mm.
5. Lead one end of the new trimming lines (12d) through the small eyelet on the
trimming spool (12c) in direction of the arrows (Fig. 27).
6. Insert two trimming lines (12d) all the way until the end then bend them over.
7. Wind all the trimming lines rmly around the trimming spool (12c) in direction
of the arrows on the trimming spool (12c) (Fig. 28).
Spare parts/Replacement parts
Power cord
Spare parts are available at an authorised dealer or through our customer
service.
If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualied persons in order to avoid a safety hazard.
12c
12d
Fig. 27
Fig. 28

Titan TTB820GGT Specifications

General

Brand	Titan
Model	TTB820GGT
Category	Trimmer
Language	English
