Getting started...
Before you start
21
Assembly
WARNING! Before using the product, familiarise yourself with the
operating features read the entire instruction manual paying particular
attention to the safety rules and operating procedures.
Do not connect the product to power supply before it is completely
assembled.
Staples
WARNING! Only original staples that match to the precision parts of
the stapler such as the magazine (8), the striker and the shot duct (9a)
can be used.
Other manufacturers use different steel grades and sizes, which may
damage the stapler.
Select the appropriate size of the staple as shown in Fig. 1:
B
C
A
Fig. 1
Loading the magazine
1. Lift up the magazine release button (12) (Fig. 2, step 1), and the magazine
slider (8a) will automatically pop up.
WARNING! Risk of ejection injury. Keep your hand away from the
ejection direction of the magazine slider (8a).
12
13
1.
Fig. 2
1.
2.
18
8
13
8a
Fig. 3
