EN
23
In more detail...
TTI821GGT by TITAN
Trimmer head tilt adjustment
Product functions
13
10a
10b
90°
75°
60°
45°
30° 15° 0
Fig. 9
1. Press the unlock button (10) and hold it in position.
2. Move the lower pole (9) slightly up or downward (Fig. 10).
3. Release the unlock button (10) and keep moving the lower pole (9) until it
locks in place.
13
10
9
2.
Fig. 10
WARNING! Always ensure that the unlock button (10) snaps into place
after adjusting the trimmer head (13) in one of the required positions!
Never adjust to an intermediate position!
Tilt the angle of trimmer head (13) to t the ground conditions for trimming or
edging use by aligning the indicator (10a) with the indication line (10b) (Fig. 9).
