TTL758CHN
16
EN
Getting
started...
Unpack
You will need
(items not supplied)
Saw chain oil
Oil funnel
Lubrication oil
Sharpening set
(items supplied)
Guide bar (4)
saw chain (3)
Guide bar cover (22)
Spanner (23)
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any
damage. If you nd that parts are missing or show damage do
not use the product but contact your dealer. Using an incomplete
or damaged product represents a hazard to people and property.
4. Ensure that you have all the accessories and tools needed for
assembly and operation. This also includes proper personal
protective equipment.
Before you start
Assembly
Assemble the guide bar (4) and saw chain (3) before operation.
1. Chain and guide bar
1). Use only a guide bar (4) and saw chain (3) combination
according to the technical data of the product.
WARNING! The product must be fully assembled before
operation! Do not use a product that is only partly assembled
or assembled with damaged parts!
Follow the assembly instructions step-by-step and use the
pictures provided as a visual guide to easily assemble the
product
Do not connect the product to the power supply until it is
completely assembled!
Always wear gloves during assembly!
