TTL758CHN

Getting

started...

Before you start

7). The saw chain movement

is as indicated by the arrow

(Fig. 1e). Make sure the saw

chain (3) is properly placed

over the sprocket wheel (5)

of the guide bar (4).

WARNING! The direction of the saw chain ‘cutters’ must be

as indicated by the symbol and arrow on the guide bar!

Fig. 1c

12 10

Fig.1e

Fig. 1d

8). Pre-tighten the saw chain (3)

turning the tension screw (9a)

clockwise with the multitool

(23)).

9). Replace the cover (7) and

slightly tighten the retaining

nut (6) (Fig. 1f).

Fig. 1f

NOTE: Fix the retaining nut nger tight only at this stage.

The chain tension cannot be adjusted with the retaining nut

tightened - it must be loosened rst.
