Operations
1111
Operation
[Expansion M series ]
External equipments connection
By connecting a signal processor such as an equalizer or limiter between the mixer section (PR
E-AMP OUT) and the power amplifier section(AMP IN) of the M series, signals can be tailored
for desired sound output.
NOTE
Inserting a 1/4-inch phone plug into AMP IN terminal disconnects internal power amplifier section
from the mixer section.
[ External equipments connection ]
Sound Processor
Expansion M series
M series mixer-amplifier allows expansion with LINK IN and LINK OUT connector.
If you need more input and output, just this function allows you can do that.
This function affect which signals are heard when another mixer or M series mixer-amplifier are
wired to the mixer-amplifier.
M-5060/M-5120/M-5240/M-5300
