Operation
Preannounce chime
M series mixer-amplifier supply user selectable 2 kinds of preannounce chime.
The way of set up is same as follow figure .
[ Chime selection ]
Priority
This function allows talk over for MIC channel 1 and 2.
All other input signals are muted when this function is activated
during stay "ON" position.
Figure shows the priority switches and its "ON" and "OFF"
Positions.
M series mixer-amplifier supply DC + 15 Volts phantom power to
use condenser microphone with MIC 1 and 2 channels.
Figure shows the phantom power switches and its "ON" and
"OFF" positions.
Phantom power
[ Phantom and Priority ]
M-5060/M-5120/M-5240/M-5300
