Instruction manual
44
External connections
MIC
The MIC connector allows you to connect wired microphones with a 6.3 mm jack plug to the unit.
LS-OUT
The LS PLUS active TLS
®
M100 can be connected using the LS-OUT connection. The LS-OUT connection offers
the option of stereo operation. For this, please connect both devices before turning them on.
AUX IN
An external audio source can be connected using the AUX IN connection. The device has 2 connection possibili-
ties, Cinch or 3.5 mm jack.
AUX OUT
A stereo system, for example, can be connected using the AUX OUT output.
Headphones
For listening to cassettes or CDs through headphones, the devices have 6 x 3.5 mm jack plugs. When you plug
the jack of your headphones into the socket 1 ( ), the built-in speaker is muted.
USB
You can charge your mobile device such as tablet or smartphone via the USB port on the front panel. You can
play your music les back in the media player via the USB connection.
