STEERING LOCK (EN/SMR/SMM)
The steering lock (1) is located on the left side of the steering head.
This device allows you to block the rotation of the handlebar, preventing
the motorcycle from being driven.
To lock the steering, rotate the handlebar fully to the right, move the
protective tab (2), insert the key, turn it to the left and press it all the way
down. Keeping it pressed down, turn it to the right and remove it.
WARNING
NEVER LEAVE THE KEY IN THE LOCK ONCE YOU HAVE LOCKED THE STEERING.
THE KEY MAY BEND OR BREAK IF YOU STEER TO THE LEFT.
TANK CAP
The fuel cap (1) is located on top of the tank.
To open it, unscrew the tank cap by rotating it anticlockwise.
To close it, place the tank cap on the filler neck and rotate it clockwise.
Arrange the tank bleeder hose (2) avoiding bends or crushing and make
sure it is inserted correctly.
FUEL TAP (450F SMR/SMM - ALL 530F)
The tap (1) is found on the left side of the engine at the bottom of the tank.
OFF In the OFF position, the fuel tap is closed.
ON In the ON position, the fuel tap is open.
Turn the knob to ON when using the motorcycle so that the fuel
flows to the carburettor and the tank empties down to the reserve.
RES IN the RES position, the reserve is used. After filling up, do not
forget to move the knob back to the ON position.
1
2.4 OTHER CONTROLS
1
1
