4 STROKES
6.2 ENGINE TECHNICAL DATA
530F SMX
MOTORCYCLE MODEL
530F EN 530F MX 530F SMR/SMM
ALL 530F ENGINE TECHNICAL DATA
KEY: E.S. = Electric start K.S. = Kick start
Type
Displacement
Bore/stroke
Compression
Fuel
Distribution
A / S camshafts
Suction valve diameter
Exhaust valve diameter
Cold suct. valve clearance
Cold exh. valve clearance
Engine shaft supports
Connection rod bearing
Pin coating
Piston
Segments
Lubrication
Engine Oil
Oil amount (oil change / engine overhaul)
Straight tooth gear primary transmission
Clutch
Gearbox (with front couplings)
Gear ratios
Ignition
Kokusan generator
Kokusan generator with E.S. - optional
NGK spark plug
Electrode distance
Cooling
Fluid amount
Start
RON 95 unleaded fuel (ethanol allowed <10%)
4 overhead valve twin cam driven by silenced chain
Kokusan digital CDI variable advance
NGK CR 8E
0.8 mm
fluid, 40% antifreeze, 60% water (up to -25°C) - circulation forced with pump
0.20mm
0.25 mm
2 ball bearings
Silver needle roller bearing
Chrome
Forged light alloy
2 segments + 1 oil scraper
2 oil pumps (1 for delivery +1 for recovery)
SAE 10W-50 API SM - JASO MA2 brand oil
1.4 / 1.5 litres
21 / 53
with multiple discs in oil bath
5 gears
Twin cam single cylinder 4-stroke, liquid-cooled
528 cm
3
98x70 mm
11.3 : 1 11.9 : 1 11.3 : 1 12.4 : 1
36 mm
31 mm
36 mm Ti
31 mm Ti
36 mm
31 mm
36 mm Ti
31 mm Ti
14:28
17:25
19:23
21:21
24:19
16:27
17:24
16:19
21:21
23:20
14:28
17:25
19:23
21:21
23:20
16:27
17:24
16:19
21:21
23:20
12V 180W
-
-
12V 180W
12V 180W
-
-
12V 180W
E.S.+K.S. K.S. (E.S.opt.) E.S.+K.S. K.S. (E.S.opt.)
1 litre1.3 litres 1.3 litres
N2/N3 SM2/C1
1
a
2
a
3
a
4
a
5
a
