Name
Physical Reference
Specification
Model
Remarks
Hex bit
Bit 2.5mm x length
100mm
Used for outer cover
of camera module
Hex wrenches
M1.5–M10
Used for Base and
Control box
Extension bit
Holder
1/4 inch
At least 150mm
magnet type is
recommended
Used for internal
box's fixed screws..
Hex socket bit
M10
Used for internal
box's fixed screws,
magnet type is
recommended.
Phillips screw
driver
Used for control box
components
Tweezer
Used for removing
cables
Adjestable
spanner
8 inch
Used for robot cable
Diagonal
cutting plier
Used for cutting
cable ties
Long nose plier
Used for removing
cables
Cable tie
120 × 2.5 mm
2
Used for securing
wires
Cable tie
150 × 3.6 mm
2
Used for securing
wires
Multimeter
Used for checking
voltage and circuit
Precision
screwdriver set
T06151
Used for screws
Electrical tape
Width: 18mm
Used for wrapping
around camera
cable connectors
USB flash drive
Used for Windows
recovery
Dongle key
Techman Robot
Must contain
authorization key of
maintenance
2-cm Plate
calibration
40 cm × 30 cm
Techman Robot
Used for camera
calibration
