Disassembly and assembly A01 Series Joint – Joint 2
Before disassembling Joint 2, disassemble Upper arm to the End Module.
Rotate Joint 2 to the home position and ensure that all joint screws are visible.
Remove the Joint Cover of Joint 2.
Remove the Joint cable of Joint 2.
