Installation steps:
1. Align the mounting holes of the dust cover with the mounting holes of the gear box and fasten them with bolts.
2. Align the suspension with the mounting holes on the main unit as shown in the picture above and put on the
bolts, then put the bolts on the pull plate connecting the suspension and the mounting seat on the gear box.
After all parts are installed, tighten the bolts, and finally plug them in. Suspension pin and R pin.
Importance: All bolts are locked in place without shaking.
WARNING: Once the assembly bolts are not fastened in place, there will be abnormal noises when the
machine is working.
