TMG TMG-RT83 - Blade Axle Assembly

PARTS LIST
www.tmgindustrial.com 25/35 Toll Free:1-877-761-2819
Ref.No.
Description
Qty
Ref.No.
Description
Qty
A1
Panel hood
1
A9
R pin 4
3
A2
Extension tube plate
1
A10
Hitch bracket-lower
2
A3
Full-thread hexagon bolts
M12x50
2
A11
Lower hanging platen
2
A4
Locknut M12
2
A12
Hexagon head bolts M18x70
4
A5
Plain washer Ø12
4
A13
Locknut M18
4
A6
Raker
1
A14
Plain washer Ø18
8
A7
Raker pin
1
A15
Hitch pin-lower
2
A8
Square pipe plug 41x41
1
3. Blade axle assembly
Ref.No.
Description
Qty
Ref.No.
Description
Qty
B1
Blade axle
1
B7
Dust cover
2
B2
Right blade
24
B8
Transmission gear
1
B3
Left blade
24
B9
End cover
1
B4
Full-thread hexagon bolts
（
fine pitch
）
M14x1.5x40
96
B10
Plain washer Ø12
15
B5
Locknut (fine pitch
）
M14x1.5
96
B11
Spring washer Ø12
15
B6
Spring washer Ø14
96
B12
Full-thread hexagon head
bolts M12x40
15
PARTS LIST
