TMG TMG-RT83 - Page 28

PARTS LIST
www.tmgindustrial.com 28/35 Toll Free:1-877-761-2819
Ref.No.
Description
Qty
Ref.No.
Description
Qty
C1
Side plate-L
1
C9
Full-thread hexagon bolts
M12x50
2
C2
Bearing seat
1
C10
Spring washer Ø12
17
C3
Deep groove ball bearing 6310
1
C11
Plain washer Ø12
25
C4
Shaft seal FB-55x80x8
1
C12
Full-thread hexagon bolts
M12x45
1
C5
O-ring 125x3
1
C13
Full-thread hexagon bolts
M12x35
4
C6
Skid plate-L
1
C14
Locknut M12
4
C7
Adjustable plate
1
C15
Hexagon nuts M12
17
C8
Small gear plate
1
C16
Sheet gasket
1
5. Right Panel Assembly
Ref.No.
Description
Qty
Ref.No.
Description
Qty
D1
Slide plate-R
1
D12
Spring washer Ø12
9
D2
Bearing seat
1
D13
Plain washer Ø12
13
D3
Shaft seal FB-45x70x8
1
D14
Full-thread hexagon bolts
M12x35
8
D4
Deep groove ball bearing 6308
1
D15
Adjustable plate
1
D5
Washer
1
D16
Small gear plate
1
D6
Plain washer Ø16
1
D17
Full-thread hexagon bolts
M12x50
2
D7
Full-thread hexagon bolts
M16x45
1
D18
Skid plate-R
1
D8
Spring washer Ø16
1
D19
Full-thread hexagon bolts
M12x45
1
D9
Cover plate
1
D20
Hexagon nuts M12
3
D10
Sheet gasket
1
D21
Locknut M12
2
D11
Grease nipple M10x1
1
PARTS LIST
