PARTS LIST
PARTS LIST
www.tmgindustrial.com 32/35 Toll Free:1-877-761-2819
Ref.No.
Description
Qty
Ref.No.
Description
Qty
F1
Gear box
1
F13
Full-thread hexagon bolts
M14x50
1
F2
Full-thread hexagon bolts
M12x40
4
F14
Chain hanger
1
F3
Plain washer Ø12
8
F15
Full-thread hexagon bolts
M18x50
1
F4
Locknut M12
4
F16
Locknut M18
3
F5
Reinforcement tube
1
F17
Plain washer Ø18
6
F6
Full-thread hexagon bolts
M16x40
8
F18
Pulling plate
1
F7
Spring washer Ø16
8
F19
Full-thread hexagon bolts
M18x55
2
F8
Plain washer Ø12
8
F20
Guard
1
F9
Full-thread hexagon bolts
M14x40
1
F21
Spring washer Ø8
2
F10
Locknut M14
2
F22
Plain washer Ø8
2
F11
Plain washer Ø14
2
F23
Full-thread hexagon bolts
M8x16
2
F12
Large plain washer Ø14
2
F24
Connecting plate
1
8. Side drive assembly
Ref.No.
Description
Qty
Ref.No.
Description
Qty
G1
Gear
1
G9
Washer
2
G2
Gear plate
1
G10
Round nut M39x1.5
1
G3
Gear
1
G11
Retaining rings for bores
110-A
1
G4
Bush
1
G12
HSCS-countersunk M16x30
2
G5
Shaft foe mid gear
1
G13
Gear
1
G6
Cylinder roller bearing
NUP310E
1
G14
Adjustable plate
1
G7
Bush
1
G15
Gear washer
1
G8
Washer
1
