USER MANUAL SAGA
Page 12 of 47
Bottom View
Docking Station
# Description
1. Gutters for docking on the SAGA Bracket
2. Device label
3. Dock security ribbon for SAGA Bracket
Data Recorder
# Description
1. Docking connector (contact points)
2. Gutters for docking on the Docking Station or Bracket
3. Device label
4. Dock security ribbon for SAGA Bracket
