USER MANUAL SAGA

Page 27 of 47

5 PERFORM A MEASUREMENT

SAGA supports a variety of usage scenarios:

• Streaming data in stationary use (5.1).

• Streaming data in portable setting via wireless connection (5.2).

• Streaming data in portable setting via optical fiber (5.3).

• Ambulatory recording without data streaming (5.4).

Perform Stationary Measurement

The stationary measurement setup consists of a setup where the data acquisition

PC and measurement device are on a fixed place and do not move throughout the

experiment. The Data Recorder is docked in the Docking Station.

Advantages

• Maximum data throughput and signal bandwidth at all channels

(4000/4096 Hz).

• Most reliable data transmission.

• Virtually unlimited recording time.

• System can be mounted to a trolley, (medical) DIN rail.

Disadvantages

• Limited freedom of movement for subject.
