TMT Automation BOXER500E - Installation Guide; Standard Installation Demonstration; Device Description

2.1 STANDARD INSATLLATION DEMONSTARATION
1. 24Vdc Sliding motor
2. Transmitter
3. safety photo Sensor
4. Flashing light
2. INSTALLATION:
4
2
1
2.2 DESCRIPTION OF DEVICE
a. Operation gear
b. Limit switch device
c. 24Vdc motor
d. Back-up batteries (Optional)
e. Release device
f. Control panel
g. Terminals of devices
h. Green Box (Optional)
e
h
f
g
a
b
c
d
INSTRUCTIONS BOXER500E / BOXER800E SLIDING GATE OPENER USER MANUAL
