Toa DM-524B - Dimensional and Circuit Diagrams; Frequency Response

[DM-524b]
Receptacle
BTS21R3A
ø41
3-ø3.2
Countersink
129
532
ø33
120°
Shield
26
ø25
ø40
Plug BTS21P3B
Chassis ground
[YM-121]
250
367
20 53
XLR-3-11C or equivalent
BTS21P3B
Receptacle
BTS21R3A
ø41
3-ø3.2
Countersink
ø33
120°
Shield
26
ø25
154
557
Plug BTS21P3B
Chassis ground
ø40
[DM-524S]
*0dB=1V
50 100 200 500 1 k 2 k 5 k 10 k
- 30
- 20
- 10
0
10
20
(dB*)
(Hz)
5. DIMENSIONAL AND CIRCUIT DIAGRAMS
6. FREqUENCY RESPONSE
(DM-524b, DM-524S)
URL:http://www.toa.jp/
133-04-00007-00
Unit:mm
The symbol mark above
is not applied to YM-121.
