11
PC
Switching hub
DP-SP3
DP-SP3
PC
Switching hub
DP-SP3
DP-SP3
DP-SP3
DP-SP3
DP-SP3
DP-SP3
Switching hub
Contact output device
Contact output device
DP-SP3
DP-SP3
PC
M-864D
External control device
External control device
[Controlling multiple DP-SP3 units (up to 4 units)]
[Controlling 5 or more DP-SP3 units]
It is possible to control DP-SP3 units by activating multiple DP-SP3 PC Software programs.
7.4. Control by Various Types of Devices
This exampleshowsa method tocontrolmultipleDP-SP3units (upto 4 units) by aPC,thecontact output
devices, the external control devices, and the M-864D.
