Toa DP-SP3 - Mounting in a Rack; CONNECTION

20
DP-SP3
To LAN
To the output terminals of
contact output devices
M-864D
Power amplifier
Spearker
Subwoofer
Spearker
Subwoofer
14. CONNECTION
14.1. Connection Example
13.2. Mounting in a Rack
(Whenrackmountingscrewsaresupplied)
The supplied rack-mounting screws can be used for
the TOA equipment rack only. Do not use them for
other racks.
When installing the unit in a rack other than that of
TOA, be sure to use the screws with a diameter of
over5mm(0.2”)andlengthofover12mm(0.47”)to
mount the unit.
Failure to do so may cause the unit to fall, resulting in
personal injury.
(Whenrackmountingscrewsarenotsupplied)
Rack mounting screws are not supplied with the unit.
Besuretousethescrewswithadiameterofover5
mm(0.2”)andlengthofover12mm(0.47”)tomount
the unit.
Failure to do so may cause the unit to fall, resulting in
personal injury.
CAUTION
DIGITAL
SPEAKE R
PROCES SOR
DP-SP3
PRESET
STATUS
1
RUN
LINK
4
3
2
INPUTS
PEAK
+12
1
2
0
–
40
OUTPUTS
PEAK
POWER
ON
OFF
+12
0
1
2
3
4
5
6
MUTE
–
40
