A
PPLICATIONS
A/V Rentals
Airports
Audio/Visual
Auditoriums / Theatres
Banks
Bars / Lounges / Nightclubs
Boardrooms
Business Music
Conference Facilities
Convenience Stores
Educational Facilities
Fitness Clubs / Gymnasiums
Hotels / Hospitality
Houses of Worship
Industrial / Warehouses
Museums
Music Distribution
Offices
Public Address
Restaurants
Retail Stores
Theme Parks
Training Rooms
Type 8-channel mixer/pre-amplifier
Output Power +4 dBm, +20 dBm (max.)
Power Bandwidth 30 - 20k Hz, +20 dBm 0.5% THD
250 - 20k Hz, +18 dBm 0.5% THD
Frequency Response 20 - 20k Hz, ±1 dB
Total Harmonic 0.01% at 1k Hz, rated output
Distortion
Inputs 8 input ports: every port accepts any input module
1 Bridging Input/Output
Input Sensitivity Input port #1 to #8: 100 mV / 10k Ω
& Impedance Bridging Input/Output: 100 mV / 3.3k Ω
Outputs Main: Balanced, 150/600 Ω
Aux: Unbalanced, 10k Ω, 0 dBm
Output Regulation Less than 1.5 dB, no load to full load
(1k Hz)
Dynamic Range Master volume set to min.: 90 dB
(Band Pass: 20 - 20k Hz, Master volume set to max.: 77 dB
with Tone Controls centered)
Tone Controls Bass: ±10 dB at 100 Hz; Treble: ±10 dB at 10k Hz
Indicators Normal, Peak, Power, Protect, and Signal LEDs
Protection Self-protection, with internal AC fuses
Power Consumption 18 W
Temperature Range 12° F to 140° F (-10° C to +60° C)
Color Black
Dimensions (W x H x D) 16.5” x 3.9” x 12.1” (420 x 99.1 x 307.5 mm)
Weight (without modules)
11.7 lbs (5.3 kg)
Other Features Output connects approx. 5 seconds after switching power on.
900 SERIES
MIXER/PRE-AMPLIFIER
Tel:800-733-7088
Fax: 800-733-9766
www.toaelectronics.com
S
PECIFICATIONS
Visit www.toaelectronics.com to download:
900 Series Architect and Engineering Specifications
900 Series Installation Manual
900 Series CAD Files
900 Series Module Guide
