Specifications
Type
Rated Output
Power Band Width
Frequency Response
Total Hamonic Distortion
Inputs
Input Sensitivity/Impedance
Outputs
Output Regulation (1 kHz)
Signal to Noise Ratio
(Band Pass 20 ~20,000 Hz)
Tone Controls Centered
Tone Contols
Controls
Indicators
Protection
Connectors
Power Consumption
Temperature Range
Dimensions (W) x (H) x (D)
Weight
Color
Standard Accessories
Other Features
8-channel mixer preamplifier
+4 dBm, +20 dBm (max.)
30 ~20,000 Hz, +20 dBm 0.5% THD
25 ~20,000 Hz, +18 dBm 0.5% THD
20 ~20,000 Hz, ± 1 dB
0.01% at 1 kHz, rated output
Eight Input Ports : Each port accepts any input module.
One Bridging Input/Output
Input Port #1 to #8 : 100 mV/10k ohms
Bridging Input/Output :100 mV/3.3k ohms
Main : Balanced, 150/600 ohms
Aux : Unbalanced, 10k ohms, 0 dBm
Less than 1 .5 dB, no load to full load
Master volume min : 90 dB
Master volume max : 77 dB
Bass: ± 10 dB at 100 Hz, Treble : ± 10 dB at 10 kHz
8 Input gain controls 1 Master gain control
1 Bass tone control 1 Treble control
1 Power ON/OFF switch 1 Tone defeat switch
1 Power LED, 1 Protect LED, 1 Signal LED, 1 Normal LED,
1 Peak LED
Self-protection, with AC fuse (inside)
Input No.1 to No. 8 .................. Card-edge connector
Bridging, Aux output ............... RCA phono jack
Output ..................................... Screw-terminal strip
Mute, Remote VR ................... Screw-terminal strip
AC power cord/plug ................ SJT, 3-prong type
AC outlet ................................. 3-pin grounding type
18W
-10°C~+60°C(12°F~140°F)
420 x 99.1 x 307.5 mm (16.5 x 3.9 x 12.1 in.)
5.3 kg(11.7lb.)
Black
4 Volume control covers (YA-920)
Output disconnected for approx. 5 seconds after switching power on.
Specifications are subject to change without notice.
