GENERAL PURPOSE BROADCAST REMOTE MICROPHONE
Remote Microphone
General Purpose Broadcast
4-2-2_
MESSAGE 1
Message 1
(Selected)
Zone 1
Group 1
Group 3
Zone 2
Zone 3
Zone 4
Broadcast
Zones
Step 2. End of broadcast
(1) When the message broadcast is finished, the Message indicator goes out.
(2) Pressing the Message key again during broadcast will terminate the broadcast.
(4) Message Broadcast Operation
Messages (1 – 5) assigned to broadcast groups require to be programmed into the VM amplifier.
Step 1. Start of broadcast
Select the desired message with the MESSAGE key (MESSAGE 1 – 5).
The Message indicator will light only when broadcast is possible.
Tip: The message broadcast can also be made by applying a control signal to the
VM amplifier's rear-mounted CONTROL I/O connector.
The Recorded voice message is broadcast to its designated broadcast group.
Recorded
message
To Next Page
