Toa Venas VM-2120 User Manual

NOMENCLATURE
Nomenclature (VM Amplifier)
3-1
Power switch
Power indicator
Treble control
Bass control
Input volume control
Master volume control
Reset key
Zone indicator
Zone selector key
Zone volume control
Name label
Name label
All-zone broadcast indicator
All-zone broadcast key
Emergency indicator
Failure indicator
Level meter
Audio input
terminal
BGM input jack
BGM input volume control
Line output jack
Recording output jack
Preamplifier output jack
Power amplifier input jack
Link connector
Remote microphone
input volume control
Chime volume control
Telephone paging volume control
External connection terminal
EV-200
SV-200M
Function switch
Control input and output connector
Attenuator control, external speaker input,
speaker output connector
24 V DC power input
AC inlet
Fuse holder
Signal earth
terminal
System Management Amplifier VM-2120/-2240
[Front]
[Rear]
