A. Location and Function of Controls
The following information provides a basic description of the toaster controls, their location and the function they
perform. The operator must be familiar with the controls.
Figure 3-1
Operation Controls
(Model 1D3 shown. Models 1 BBS and 1 D22B operation control are basically the same as the Model 1 D3)
1. Operating Lever
Lowering the operating lever lowers the bread into the toasting chambers. When the toast has reached its
set darkness the operating lever and the toast will automatically be raised.
2. Color Selection Knob
Color selection knob is used to set the desired darkness of the toast.
3. Manual Release Lever
Manual release lever is used to manually raise the toast during the toasting cycle.
9
Lever
Lever
Selection
Knob
