SECTION 3 - OPERATION
B.
Operation Procedure
1. Insert bread into toaster slots.
IMPORTANT: On Model 1D22B bun toasters the buns must be inserted
so the side to be toasted faces the heating elements. The heating
elements are located as shown in Figure 3-2.
2. Positon color selection knob at desired darkness. A medium color
setting is 9 o'clock. Turn left for lighter toast and right for darker toast.
NOTE: It will be necessary to determine the color setting for each different
product you toast. Test a single piece at a 9 o'clock setting and then
increase or decrease as necessary.
3. Lower the operating lever to lower the bread into the toasting
chambers.
4. Wait for the completion of the cycle, and toast will automatically be
raised.
Side of bun to be toasted must
face the heating element.
Heating elements are on the side
of the slots as shown.
1D22B Top View
Figure 3-2
10
